General Specifications:

• Form Factor: Micro ATX
• Chipset: Intel H510
• CPU Support: 10th Gen Intel Core, Pentium Gold, and Celeron processors / 11th Gen Intel Core processors
• Socket: LGA 1200

Memory:

• Memory Slots: 2 x DDR4 DIMM slots
• Memory Type: DDR4
• Max Memory: Up to 64GB
• Memory Speed: Supports DDR4 3200 (OC) / 2933 / 2800 / 2666 / 2400 / 2133 MHz

Graphics:

• Integrated Graphics Support: Yes (depends on CPU)
• Display Outputs:
  • 1 x HDMI (4K @ 60Hz)
  • 1 x D-Sub (VGA)
• Multi-Graphics Support: Not supported (Single GPU only)

Expansion Slots:

• PCIe 3.0 x16: 1 slot
• PCIe 3.0 x1: 1 slot

Storage:

• SATA III: 4 x SATA3 6.0 Gb/s connectors
• M.2 Slot: 1 x M.2 slot (Key M) supporting up to 32Gb/s (PCIe 3.0 x4) and SATA3 modes for SSDs

Audio:

• Audio Codec: Realtek ALC887/897 7.1 Channel High Definition Audio Codec

Networking:

• LAN: 1 x Realtek RTL8111H, 1 x Gigabit LAN port

Rear I/O Ports:

• 1 x PS/2 Mouse/Keyboard Port
• 1 x D-Sub Port
• 1 x HDMI Port
• 1 x LAN (RJ45) Port
• 4 x USB 3.2 Gen1 Ports
• 2 x USB 2.0 Ports
• 3 x Audio Jacks

Internal I/O Connectors:

• 1 x 24-pin ATX Power Connector
• 1 x 8-pin 12V Power Connector
• 1 x USB 3.2 Gen1 Header
• 1 x USB 2.0 Header
• 1 x Front Panel Audio Header
• 1 x COM Port Header
• 1 x TPM Header
• 1 x Chassis Intrusion Header
• 1 x CPU Fan Connector (4-pin)
• 1 x Chassis Fan Connector (4-pin)

BIOS:

• BIOS Type: 128Mb AMI UEFI Legal BIOS with GUI support
• Features: ACPI 6.0, SMBIOS 2.7, and more

Special Features:

• ASRock Super Alloy
• Full Spike Protection
• ASRock Full HD UEFI
