Supports 10th Generation Intel Core™ Processor Intel H510 single chip architecture Supports 2-DIMM DDR4- 2933/ 2666/ 2400/2133/ 1866 up to 64 GB Memory Supports PCIe 3.0 Supports PCIe M.2 (32Gb/s) Supports USB 3.2 Gen1 Essentials

• Product Collection10th Generation Intel® Core™ i3 Processors

• Code NameProducts formerly Comet Lake

• Vertical SegmentDesktop

• Processor Numberi3-10100

• StatusLaunched

• Launch DateQ2'20

• Lithography14 nm

• Use ConditionsPC/Client/Tablet CPU Specifications

• # of Cores4

• # of Threads8

• Processor Base Frequency3.60 GHz

• Max Turbo Frequency4.30 GHz

• Cache6 MB Intel® Smart Cache

• Bus Speed8 GT/s

• Intel® Turbo Boost Technology 2.0 Frequency‡4.30 GHz

• TDP65 W Supplemental Information

• Embedded Options AvailableNo

• DatasheetView now Memory Specifications

• Max Memory Size (dependent on memory type)128 GB

• Memory TypesDDR4-2666

• Max # of Memory Channels2

• Max Memory Bandwidth41.6 GB/s

• ECC Memory Supported ‡No Processor Graphics

• Processor Graphics ‡Intel® UHD Graphics 630

• Graphics Base Frequency350 MHz

• Graphics Max Dynamic Frequency1.10 GHz

• Graphics Video Max Memory64 GB

• 4K SupportYes, at 60Hz

• Max Resolution (HDMI)‡4096 x 2160@30Hz

• Max Resolution (DP)‡4096 x 2304@60Hz

• Max Resolution (eDP - Integrated Flat Panel)‡4096 x 2304@60Hz

• DirectX* Support12

• OpenGL* Support4.5

• Intel® Quick Sync VideoYes

• Intel® InTru™ 3D TechnologyYes

• Intel® Clear Video HD TechnologyYes

• Intel® Clear Video TechnologyYes

• # of Displays Supported ‡3

• Device ID0x9BC8 Expansion Options

• Scalability1S Only

• PCI Express Revision3.0

• PCI Express Configurations ‡Up to 1x16, 2x8, 1x8+2x4

• Max # of PCI Express Lanes16 Package Specifications

• Sockets SupportedFCLGA1200

• Max CPU Configuration1

• Thermal Solution SpecificationPCG 2015C

• TJUNCTION100°C

• Package Size37.5mm x 37.5mm Advanced Technologies

• Intel® Optane™ Memory Supported ‡Yes

• Intel® Thermal Velocity BoostNo

• Intel® Turbo Boost Max Technology 3.0 ‡No

• Intel® Turbo Boost Technology ‡2.0

• Intel vPro® Platform Eligibility ‡No

• Intel® Hyper-Threading Technology ‡Yes

• Intel® Virtualization Technology (VT-x) ‡Yes

• Intel® Virtualization Technology for Directed I/O (VT-d) ‡Yes

• Intel® VT-x with Extended Page Tables (EPT) ‡Yes

• Intel® Transactional Synchronization ExtensionsNo

• Intel® 64 ‡Yes

• Instruction Set64-bit

• Instruction Set ExtensionsIntel® SSE4.1, Intel® SSE4.2, Intel® AVX2

• Idle StatesYes

• Enhanced Intel SpeedStep® TechnologyYes

• Thermal Monitoring TechnologiesYes

• Intel® Identity Protection Technology ‡Yes

• Intel® Stable Image Platform Program (SIPP)No Security & Reliability

• Intel® AES New InstructionsYes

• Secure KeyYes

• Intel® Software Guard Extensions (Intel® SGX)Yes with Intel® ME

• Intel® OS GuardYes

• Intel® Trusted Execution Technology ‡No

• Execute Disable Bit ‡Yes

• Intel® Boot GuardYes
