General Specifications:

• Form Factor: Micro ATX
• Chipset: Intel H610
• CPU Support: 12th and 13th Gen Intel Core, Pentium Gold, and Celeron processors
• Socket: LGA 1700

Memory:

• Memory Slots: 2 x DDR4 DIMM slots
• Memory Type: DDR4
• Max Memory: Up to 64GB
• Memory Speed: Supports DDR4 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 MHz (depending on CPU)

Graphics:

• Integrated Graphics Support: Yes (depends on CPU)
• Display Outputs:
  • 1 x HDMI 2.1 (4K @ 60Hz)
  • 1 x D-Sub (VGA)
• Multi-GPU Support: Not supported (Single GPU only)

Expansion Slots:

• PCIe 4.0 x16: 1 slot
• PCIe 3.0 x1: 2 slots

Storage:

• SATA III: 4 x SATA3 6.0 Gb/s connectors
• M.2 Slot: 1 x M.2 slot (Key M) supporting PCIe 3.0 x4 and SATA modes for SSDs

Audio:

• Audio Codec: Realtek ALC897 7.1 Channel High Definition Audio Codec

Networking:

• LAN: 1 x Realtek RTL8111H, 1 x Gigabit LAN port

Rear I/O Ports:

• 1 x PS/2 Keyboard/Mouse Combo Port
• 1 x D-Sub Port
• 1 x HDMI Port
• 2 x USB 3.2 Gen 1 Ports
• 4 x USB 2.0 Ports
• 1 x LAN (RJ45) Port
• 3 x Audio Jacks

Internal I/O Connectors:

• 1 x 24-pin ATX Main Power Connector
• 1 x 8-pin ATX 12V Power Connector
• 2 x USB 3.2 Gen 1 Headers
• 2 x USB 2.0 Headers
• 1 x M.2 Socket 3 Connector
• 4 x SATA 6Gb/s Connectors
• 1 x Front Panel Audio Connector
• 1 x COM Port Header
• 1 x TPM Header
• 1 x Clear CMOS Jumper
• 1 x CPU Fan Connector (4-pin)
• 1 x Chassis Fan Connector (4-pin)

BIOS:

• BIOS Type: 128Mb Flash ROM, UEFI AMI BIOS
• Features: DMI 4.0, WfM 2.0, SMBIOS 3.3, ACPI 6.2, PnP 1.0a, Multi-language BIOS

Special Features:

• ASUS 5X Protection III
• AI Overclocking
• ASUS OptiMem II
• Fan Xpert
