General Specifications:

• Form Factor: ATX
• Chipset: AMD X670E
• CPU Support: AMD Ryzen 7000 Series processors
• Socket: AM5

Memory:

• Memory Slots: 4 x DDR5 DIMM slots
• Memory Type: DDR5
• Max Memory: Up to 128GB
• Memory Speed: Supports DDR5 6400+ (OC), 6200+ (OC), 6000+ (OC), 5600, 5400, 5200, 4800 MHz

Graphics:

• Integrated Graphics Support: Yes (depends on CPU with integrated GPU)
• Display Outputs:
  • 1 x HDMI 2.1 port (4K @ 60Hz)
  • 1 x DisplayPort 1.4 (8K @ 60Hz)

Expansion Slots:

• PCIe 5.0 x16: 2 slots (x16 or x8/x8 mode)
• PCIe 4.0 x16: 1 slot (x4 mode)
• PCIe 4.0 x1: None

Storage:

• SATA III: 6 x SATA 6.0 Gb/s connectors
• M.2 Slots:
  • 2 x M.2 slots (PCIe 5.0 x4)
  • 2 x M.2 slots (PCIe 4.0 x4)

Audio:

• Audio Codec: ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080
• Special Features: Impedance sense for front and rear headphone outputs, Dual OP Amplifiers

Networking:

• LAN: 1 x Intel 2.5Gb Ethernet
• Wi-Fi: Wi-Fi 6E (802.11 a/b/g/n/ac/ax) with 2x2 MU-MIMO, supports 6GHz band
• Bluetooth: Bluetooth 5.2

Rear I/O Ports:

• 1 x HDMI 2.1 Port
• 1 x DisplayPort 1.4
• 1 x Intel 2.5Gb Ethernet Port
• 6 x USB 3.2 Gen 2 Type-A Ports
• 1 x USB 3.2 Gen 2x2 Type-C Port
• 4 x USB 2.0 Ports
• 1 x Optical S/PDIF Out
• 5 x Gold-plated Audio Jacks
• 2 x Antenna Connectors (for Wi-Fi)

Internal I/O Connectors:

• 1 x 24-pin ATX Main Power Connector
• 2 x 8-pin ATX 12V Power Connectors
• 1 x USB 3.2 Gen 2x2 Header (supports USB Type-C®)
• 1 x USB 3.2 Gen 1 Header
• 2 x USB 2.0 Headers
• 4 x SATA 6Gb/s Connectors
• 4 x M.2 Sockets (with support for up to 22110 M.2 SSDs)
• 1 x Front Panel Audio Connector
• 1 x Clear CMOS Jumper
• 1 x Front Panel Connector
• 1 x RGB Header
• 1 x ARGB Header
• 1 x CPU Fan Header
• 3 x Chassis Fan Headers
• 1 x AIO Pump Header
• 1 x Water Cooling Pump Header

BIOS:

• BIOS Type: 256Mb Flash ROM, UEFI BIOS
• Features: DMI 4.0, WfM 2.0, SMBIOS 3.3, ACPI 6.2, PnP 1.0a, Multi-language BIOS

Special Features:

• AI Overclocking
• AI Cooling
• AI Networking with GameFirst VI
• ASUS OptiMem II
• ROG DIMM.2
• Aura Sync RGB Lighting

Other Features:

• ROG SupremeFX Audio Technology
• Sonic Studio III + Sonic Studio Virtual Mixer
• DTS® Sound Unbound
• ROG AI Overclocking
• ROG AI Cooling
• Dynamic OC Switcher
• PCIe Slot Q-Release
• M.2 Q-Latch
