General Specifications:

• Form Factor: Micro ATX
• Chipset: AMD A620
• CPU Support: AMD Ryzen 7000 Series processors
• Socket: AM5

Memory:

• Memory Slots: 2 x DDR5 DIMM slots
• Memory Type: DDR5
• Max Memory: Up to 64GB
• Memory Speed: Supports DDR5 6000+ (OC), 6400+ (OC), 6200 (OC), 5800 (OC), 5600 (OC), 5200, 4800 MHz

Graphics:

• Integrated Graphics Support: Yes (depends on CPU with integrated GPU)
• Display Outputs:
  • 1 x HDMI 2.1 (4K @ 60Hz)
  • 1 x DisplayPort 1.4 (8K @ 60Hz)

Expansion Slots:

• PCIe 4.0 x16: 1 slot
• PCIe 3.0 x1: 2 slots

Storage:

• SATA III: 4 x SATA 6.0 Gb/s connectors
• M.2 Slot: 1 x M.2 slot (PCIe 4.0 x4) for NVMe SSDs

Audio:

• Audio Codec: Realtek ALC897 7.1 Channel High Definition Audio Codec

Networking:

• LAN: 1 x Realtek RTL8111H, 1 x Gigabit LAN port

Rear I/O Ports:

• 1 x HDMI 2.1 Port
• 1 x DisplayPort 1.4
• 1 x PS/2 Combo Port
• 2 x USB 3.2 Gen 1 Type-A Ports
• 2 x USB 2.0 Ports
• 1 x LAN (RJ45) Port
• 3 x Audio Jacks

Internal I/O Connectors:

• 1 x 24-pin ATX Main Power Connector
• 1 x 8-pin ATX 12V Power Connector
• 1 x USB 3.2 Gen 1 Header
• 2 x USB 2.0 Headers
• 1 x M.2 Slot (Key M)
• 4 x SATA 6Gb/s Connectors
• 1 x Front Panel Audio Connector
• 1 x CPU Fan Header (4-pin)
• 1 x Chassis Fan Header (4-pin)
• 1 x Clear CMOS Jumper
• 1 x Front Panel Connector

BIOS:

• BIOS Type: 128Mb Flash ROM, UEFI BIOS
• Features: DMI 4.0, WfM 2.0, SMBIOS 3.3, ACPI 6.2, PnP 1.0a, Multi-language BIOS

Special Features:

• EZ Debug LED
• Steel Armor (Reinforced PCIe Slot)
• Core Boost
• Memory Boost
• Audio Boost
